Distance spindle axis to column generating line (mm)
2250
225
Max. Distance spindle nose to table (mm)
/
6+30
Max. Distance spindle nose to base (mm)
550
1670
Spindle taper
MT3
MT3
Spindle speeds range (r/min)
100-2900
100-2900
Spindle speeds series
8
8
Dimension of worktable surface (mm)
/
Φ440
Table travel (mm)
560
560
Dimension of base (mm)
690 X 500
690 X 500
Overall height (mm)
1390
1900
Main motor (KW)
1.1/0.75
1.1/0.75
Coolant motor (W)
40
40
G.W/N.W (kg)
235/225
300/290
Packing dimension (cm)
75 X 52 X 117
70 X 56 X 182
PURROS Machinery have various types of Hydro Speed Regulators, Self-Feeding Drill Heads(Units), Multi-Spindle Drill Heads and Servo feed tapping machine, Special Purpose Machines, warmly waiting for you to inquire.
